ESD trolley 3W-9805208-2(1100*715*1400mm)
Technical advantages
The anti-static collection rack is made of high-quality cold-rolled steel plate, which is sturdy and durable. Its surface is treated with a special anti-static coating, which can effectively conduct static electricity and prevent static electricity accumulation. The collection rack has an excellent anti-static index of up to 10⁶ to 10⁹Ω, which ensures that any static charge on the surface of the stored items is quickly conducted to the ground. This feature not only protects electronic components from potential damage, but also minimizes dust accumulation, providing a clean and safe storage environment for your products.
A highlight of the anti-static collection rack is its efficient storage and management capabilities. The multi-layer open structure design can store materials, semi-finished products or finished products of various specifications in an orderly manner. This thoughtful design facilitates easy access and quick retrieval, improving the workflow efficiency of production workshops and storage facilities. In addition, the shelf is equipped with label slots and partitions for easy material identification and partition management. This orderly organization not only improves storage efficiency, but also simplifies the operation process, allowing your team to focus on what is really important.
Stability and durability are critical to a storage solution, and the Anti-Static Collection Rack excels in both. Made of high-strength steel and a scientifically designed mechanical structure, the rack is built to withstand heavy loads, from 150kg to 300kg per tier (depending on the model). This strong load-bearing capacity ensures the rack can withstand frequent storage and retrieval operations without compromising its structural integrity. Even under heavy loads, the Anti-Static Collection Rack effectively resists deformation, providing you with a long-lasting and durable storage solution that meets the needs of your busy environment.
Technical Specification
| Product name | Anti-static collection rack | |
| Product model | 9805208-2 | |
| Specification parameters | ●External dimensions: | 1100*715*1400mm |
| ●Side size: | 1028*545*30(single)/40(double) | |
| ●Pallet size: | 525*250mm | |
| ●Side panel structure: | 4-piece plug-in board | |
| ●Adjustable width: | 0-445mm (Max ) | |
| ●Groove depth: | 4mm | |
| ●Groove width: | 7mm | |
| ●Pitch: | 10 | |
| ●Number of slots: | 100 | |
| ●Weight: | 72.8Kg | |
| ●PCB board storage capacity: | 300 pieces | |
| ●weight bearing: | 150kg | |
| Product description | ◆Bearing design, smooth movement | |
| ◆Double knob locking device | ||
| ◆2 single-sided panels and 1 double-sided panels | ||
| ◆Anti-silent caster material: PU material | ||
| ◆Bottom reinforced crossbar | ||
| ◆Static index: 10e4-10e8 | ||
| Temperature resistance options | 口100°C 口120°C 口150°C | |
| Optional accessories | □File box | |
| Mouth adjustment label | ||
| □Slot code label | ||
| □Anti-static label | ||
| □Anti-collision guardrail | ||
*Temperature resistance refers to the maximum temperature of the PCB board that the turnover cart can withstand
